Sealing profiles of
Q-LON - for windows and doors
Decades of experience in developing and manufacturing seals Q-LON - from a unique combination of materials and specifications that can not be achieved using other materials used in the manufacture of sealants - offers benefits that are critical when using the sealant in the extreme conditions.
There are continued research and constant self-improvement process, together with strict control of input materials and quality control of products, created one of the most reliable sealing systems in the world - a system of Q-LON.
The materials from which to create Q-Lon, a gasket attached to its combination of these characteristics, which can not be achieved using other materials used for the production of seals.
Extremely low coefficient of heat transfer K = 0.033 - the average is 10 times greater than the rate of homogeneous materials, and thus improves the quality of energy windows in general. There are continued research and constant self-improvement process, together with strict control of input materials and quality control of products, created one of the most reliable sealing systems in the world - a system of Q-LON. Installing the seal is extremely simple. Due to kickoff the seal at the corners of doors with special scissors, eliminating the need for the operation of welding the sealing profile on the corners, which eases the installation process technology. Seals Q-LON proven themselves for over 20 years. During this time the seal Q-LON has been installed in more than 100 million windows and doors around the world. Rely on our experience and quality sealants Q-LON.
Seals Q-LON - the benefits of applying:
- rational installation - directly from the reel, without preliminary
kickoff profile size
- Easy and quick installation due to kickoff the profile of the corners
wing special scissors
- excellent ability of the material to rebuild their
original form
- does not react with any types of lacquers and paints, including
with acrylic, water, absolutely neutral
- surface seal withstands handling any
cleaners, until nitrorastvorov
- high elasticity at low temperatures
- longevity
- high sound insulation
- color: brown, white, black, gray, beige, light oak.
chestnut.
- supplied on reels of 100 - 500 meters (depending on
type), 2 coils per box
Q-LON - the material and the basic functional benefits
1. Polyurethane foam - the core structure - highly elastic, including at extremely low temperatures, high regenerating ability
2.Polietilenovaya surface-protection profile - not exposed to UV and weather resistant, smooth, stain-resistant surface that withstands any cleaners
3. fiberglass yarn or polypropylene insert, prevents compression or extension, for easy mounting in the groove
We offer firm seals Dipro:
1. for wooden doors and windows
2. for windows (euro)
Sealing profiles made of thermoplastic elastomer (EPA). Properties listed in the table below.
| Properties |
ЕРА |
| Shore hardness |
60° - 65° |
| Limiting tensile strength |
6,9 МPa |
| Elongation at break |
400% |
| Cold endurance |
to -60°С |
| Heat resistance |
to +100°С |
| UV resistance |
high |
| Compression 22°С/100°С |
34% |
| Weldability |
+ |
And as we have high quality seals Schlegel. This seal is used both for wood windows, and windows from PVC. resistant strain
- little affected by temperature
- tactile
- not react with water based paints and acrylic lacquers
- always in the presence of a wide range of colors.
